1. Overview

1.1 Summary

The EM3588 SBC is a high-performance embedded computing platform built around the Rockchip RK3588 octa-core processor. Combining robust AI acceleration (6 TOPS NPU), versatile connectivity including dual GbE/WiFi 6, and support for 8x AHD cameras, it delivers exceptional edge computing capabilities. With flexible memory/storage options and multi-OS support, this board excels in industrial automation, AI vision systems, and multimedia applications.

1.2 Product Parameters

Specifications
CPU	Quad-core Cortex-A76 + Quad-core Cortex-A55
GPU	ARM Mali-G610 MP4 with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2
NPU	6 TOPS
Memory	8GB (up to 16GB)
Storage	32GB eMMC flash (up to 256GB) Micro SD card slot SATA3.0 socket 2x M.2 SSD socket (M-Key)
Power Supply	12V/3A DC input jack
USB	1x USB3.1 Type-C 2x USB3.0 Host
Connectivity	2x Gigabit Ethernet, RJ45 ports 2.4G/5G 2T2R WiFi (802.11a/b/g/n/ac/ax) with Bluetooth5.2 mPCIe socket with Nano SIM card port to support 4G LTE Module
Serial	1x Serial port for debug, 3-pin connector 1x RS232, 12-pin pluggable terminal block 1x RS485, 12-pin pluggable terminal block
Video Output	H2x HDMI 2.1, up to 8Kp60 DP to HDMI2.0, up to 4Kp60 2x MIPI DSI, up to 4Kp60
Camera/Video Input	2x MIPI CSI, for 8x AHD cameras
Audio	3.5mm audio I/O jack 2x Speaker via 12-pin pluggable terminal block
Keys	Recovery, Reset, Power
Operating Temperature	0° to + 70° C
Other features	RTC with battery connector, CAN
Dimension	Based board - 155 x 115 mm; CPU module - 62 x 48 mm
