2. Quick Setup

❶ Connect the USB-A cable from the host PC to the USB DRD port on the Compact3576.

❷ Connect the USB-to-UART cable from the host PC to the Debug port on the board. On the host PC, start a terminal emulation program (such as SecureCRT) with the following serial port settings:

BaudRate	Data Bits	Stop Bits	Parity	Flow Control
1500000	8	1	None	None

❸ Connect the board and monitor with an HDMI cable.

❹ Power on the board; it will boot up and enter the system.
