1. Overview
1.1 Summary
The Compact3576 SBC (Rockchip RK3576, octa-core CPU, Mali-G52 GPU, 6‑TOPS NPU) features a SOM/baseboard split for easy upgrades and cost savings. Rich I/O includes triple USB 3.0, dual displays, HDMI in, GbE, M.2, and mPCIe for 4G module. Targets edge AI, machine vision, digital signage, video processing, IoT gateways, and medical systems.
1.2 Product Parameters
Specifications |
|
|---|---|
CPU |
Quad-core Cortex-A72 + Quad-core Cortex-A53 |
GPU |
ARM Mali G52 MC3 with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 |
NPU |
6 TOPS |
Memory |
4GB (up to 8GB) |
Storage |
32GB eMMC flash (up to 128GB) Micro SD card slot M.2 socket for SSD |
Power Supply |
12V DC via USB-C connector (minimum 3A) |
USB |
2x USB3.0 Host 1x USB3.0 DRD (Host/device) |
Connectivity |
10/100/1000 Mbps Ethernet RJ45 port 2.4G/5G 2T2R WiFi (802.11a/b/g/n/ac) with Bluetooth5.0 mPCIe socket with Nano SIM card port to support 4G Module |
Serial Port |
Debug, 3-pin connector |
Display |
HDMI2.1, up to 4Kp120 DP1.4 to HDMI2.0, up to 4Kp60, Micro HDMI (HDMI1) |
Video input |
HDMI IN (HDMI to MIPI CSI) |
Audio |
3.5mm audio jack for Audio out S/PDIF out 8-channel audio via HDMI |
Keys |
Power, Reset, Recovery |
Operating Temperature |
0° to + 70° C |
Other features |
RTC with battery connector, IR |
Dimensions |
Based board – 152.5 x 83 mm; CPU module – 57.5 x 44.0 mm |
