1. Overview

1.1 Summary

The Compact3588S is a credit-card-sized single-board computer (SBC) with a layout similar to the Raspberry Pi 4, but based on a more powerful 64-bit octa-core Rockchip RK3588S processor. Featuring quad-core Cortex-A76 and Cortex-A55 CPUs, a Mali-G610 MC4 GPU, and a 6 TOPS NPU, it delivers efficient performance across a variety of computing tasks. It supports up to 16 GB of RAM and 256 GB of eMMC storage, and includes an M.2 slot for high-speed storage expansion. The Compact3588S offers multiple video output options, including HDMI, DP-to-HDMI, and MIPI LCD, supporting triple-display setups (e.g., 8K+4K+2K) or single-display output up to 8K. It is well-suited for scenarios requiring high-performance computing and complex processing capabilities, such as edge computing, artificial intelligence, intelligent security, industrial control, and machine vision.

1.2 Product Parameters

Specifications
CPU	Quad-core Cortex-A76 + Quad-core Cortex-A55
GPU	ARM Mali-G610 MP4 with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2
NPU	6 TOPS
Memory	8GB (up to 16GB)
Storage	32GB eMMC flash (up to 256GB) Micro SD card slot M.2 socket for SSD (optional. multiplexed with 4G module)
Power Supply	5V DC via USB-C connector (minimum 3A) 5V DC via GPIO header (minimum 3A) Power over Ethernet(PoE) enabled (requires separate PoE HAT)
USB	3x USB2.0 Host 1x USB3.0 Host/device
Connectivity	PoE-capable Gigabit Ethernet RJ45 port 2.4G/5G 2T2R WiFi (802.11a/b/g/n/ac/ax) with Bluetooth5.2 M.2 socket with Nano SIM card port to support 4G LTE Module
Debug	Debug via USB-C
Display	HDMI2.1, up to 8Kp60, Micro HDMI (HDMI0) DP1.4 to HDMI2.0, up to 4Kp60, Micro HDMI (HDMI1) MIPI DSI, up to 4Kp60, 30-pin FPC connector
Audio	3.5mm audio I/O jack
Camera	2x MIPI-CSI for camera (Multiplexed with I2C)
Keys	Recovery
Weight	58 gram
Operating Temperature	0° to + 70° C
Keys	Recovery
Expansion features	2x I2C, 1x PWM, 2x UART, 1x CAN, 1x SPI and 12x GPIO via 40-pin GPIO header
Dimension	85 x 56 mm (Raspberry Pi 4 Model B form factor)
