* Processor: Rockchip RK3128. Quad-Core Cortex-A7, 1.2GHz
* RAM: 1GB
* Storage: 8GB
* Interfaces: 2x UART, Debug, USB Host, USB OTG, Ethernet/RGB, Micro SD, LVDS/MIPI DSI, HDMI, CIF, SPI, SPDIF, Aduio I/O, CVBS, GPIO, etc.
* Operating system: Android 7.1, Debian 9
* Board size: 112 x 90 mm
EM3128 single board computer is powered by a Rockchip RK3128 quad-core Cortex-A7 processor, which integrates a Mali-400MP2 GPU. This RK3128 development board comes with 1GB RAM and 8GB eMMC flash, Ethernet, Wi-Fi and Bluetooth, and various other ports and expansion headers, and aimed at low cost and power efficient embedded projects on the market.
| Specifications | ||
|---|---|---|
| SoC | Rockchip RK3128 quad core Cortex A7 processor @ 1.2GHz | |
| GPU | Mali-400MP2 GPU | |
| Memory | 1GB DDR3L | |
| Storage | 8GB eMMC Flash Micro SD slot (Multiplexed with Debug) |
|
| Power Supply | 5V/3A DC input jack | |
| Video | Output | HDMI1.4, up to 1080p60 LVDS/MIPI/RGB, up to 1280*720 CVBS, up to 576i |
| input | DVP Sensor interface, up to 5M Pixels | |
| Audio | S/PDIF for audio output MIC1.3 for audio input 2-pin header for Line-in 3.5mm earphone jack for Audio output |
|
| Connectivity | 10/100 Mbps Ethernet port. LAN8720A controller; 802.11 b/g/n 1T1R WiFi and Bluetooth4.0 |
|
| Serial port | 1x debug, 2x UART | |
| USB | 1x USB2.0 Host (Multiplexed with WiFi), 1x USB2.0 OTG | |
| Button | Reset, Recovery | |
| Misc | IR Receiver, RTC, GPIO, ADC, SPI | |
| Dimensions | Baseboard - 112 x 90 mm; CPU module – 55 x 45 mm | |
PCB Dimension
| OS | Item | Feature | Description |
|---|---|---|---|
| Android7.1 | Boot | uboot 2014.10 | rk3128_loader_v2.05.240.bin |
| Kernel | Version | Linux3.10.104 | |
| Drivers | HDMI | Support 1080P, 720P, 480P resolution | |
| Audio | Audio out, MIC | ||
| SD card | Micro SD card (Multiplexed with Debug) | ||
| USB Host | USB2.0 Host (Multiplexed with WiFi); OTG-to-Host | ||
| USB OTG | USB2.0 OTG | ||
| Ethernet | 10/100 Mbps Ethernet | ||
| adb | adb shell | ||
| WiFi | Wireless- 2.4GHz | ||
| Bluetooth | Bluetooth 4.0 | ||
| Serial Port | Debug | ||
| RTC | Support | ||
| Embedded GUI | Android7.1 | Support Alarm Clock, Browser, Gallery, Calculator, Camera, Email, File Explorer, video player, Music etc. | |
| Cross-compiler Environment | ubuntu-16.04, java-8-openjdk-amd64.tar.bz2 | ||
| Debug Tools | SecureCRT, AndroidTool.exe, ADB | ||
| Datasheet |
|
|
|
|
|
|
| Reference Manual |
|
|
| Tools |
If you order the SBC or any question, please feel free to contact us at market@armdesigner.com
