1. Overview
1.1 Summary
Idea1126B-P SBC features Rockchip RV1126B-P quad-core ARM Cortex-A53 with 3 TOPS NPU, 2GB RAM, 8GB eMMC. It includes Gigabit Ethernet, Wi-Fi, Bluetooth, RF315, MIPI DSI, and dual MIPI CSI. Paired with 4K CMOS sensor, PIR, photovaristor, and IR/white LED, it serves as a smart door lock solution adaptable to various lighting.
1.2 Product Parameters
Specifications |
|
|---|---|
CPU |
Rockchip RV1126B-P. Quad-core Cortex-A53 @ 1.6GHz |
NPU |
3 TOPS |
Memory |
2GB/4GB LPDDR4 |
Storage |
8GB/16GB/32GB/64GB/128GB/256GB eMMC Micro SD card slot |
Power Supply |
12V/3A DC input jack Power over Ethernet (PoE) |
USB |
1x USB2.0 OTG 1x USB2.0 Host 2.0 |
Connectivity |
Gigabit Ethernet RJ45 port 2.4G WiFi (802.11b/g/n) with Bluetooth 4.2 |
Serial Port |
1x Serial port for debug, 3-pin connector 1x UART, 4-pin connector 1x RS485, 3-pin connector |
Display |
MIPI DSI, 26-pin header |
Audio |
Rockchip RK809-9 audio codec. 3.5mm Audio out jack Speaker (2-pin connector) 2x digital MEMS MIC |
Camera |
2x MIPI Cameras, 24-pin FPC connector |
Keys |
Recovery, Reset |
Other features |
GPIO, SPI, CAN, PIR, IR LED, White LED, Relay, Wiegand, Photovaristor |
Dimensions |
Based board – 162 x 95mm; CPU module - 35 x 34mm |
