1. Overview
1.1 Summary
The EM3576 is powered by Rockchip RK3576 octa-core processor with 6 TOPS NPU, ARM Mali-G52 MC3 GPU, 16-Megapixel ISP, supports 8K@30fps decoder and 4K@60fps encoder. It provides a cost-effective and energy-efficient Multi-Camera Monitoring solution for security markets such as communities, transportation, fire protection, and office parks.
1.2 Product Parameters
Specifications |
|
|---|---|
CPU |
Quad-core Cortex-A72 + Quad-core Cortex-A53, 64-bit SoC |
GPU |
ARM Mali-G52 MC3 GPU with support for OpenGL ES 1.1/2.0/3.2 OpenCL 2.0, Vulkan 1.1, AFBC |
NPU |
6 TOPS |
Memory |
4GB (up to 8GB) |
Storage |
32GB eMMC flash (up to 128GB) Micro SD card slot M.2 socket SATA3.1 socket* |
Power Supply |
12V/3A DC input jack |
USB |
1x USB3.2 Type-C 1x USB2.0 Host* |
Connectivity |
Gigabit Ethernet RJ45 portvia Realtek RTL8211F-CG controller 2.4G/5G 2T2R WiFi (802.11a/b/g/n/ac) with Bluetooth4.1 |
UART |
1x debug, 3-pin connector 2x UART(multiplexed with RGB), 4-pin connector 1x RS485, 3-pin pluggable system terminal block |
Display |
HDMI 2.1, up to 4K@120fps MIPI DSI, 2560x1600@60fps (26-pin header) RGB (multiplexed with SPI & 2x UART), 40-pin FPC connector |
Audio |
2x 3.5mm audio jack for Audio input/output 1x MIC, 2-pin connector |
Camera |
12x AHD Cameras, BNC connector |
Keys |
Recovery, Reset, Power |
Other features |
RTC with battery connector, CAN, SPI, GPIO(1x I2C, 3x GPIO) |
Operating Temperature |
0° to + 70° C |
Dimension |
Based board - 170 x 120 mm; CPU module - 57.5 x 44 mm |
* SATA and USB2.0 Host cannot be used simultaneously.
